Einsum.h File Reference

this file provides einsum operation More...

#include <cstring>
#include <string>
#include <vector>

Include dependency graph for Einsum.h:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Classes
struct	PROJECT_NS::EinsumIdx
	EinsumIdx is a struct store information of index used in einsum operation. More...
struct	PROJECT_NS::DimenHelper
	DimenHelper is a struct control dimensional utils on the orginal/einsum index for a given tensor. More...
class	PROJECT_NS::EinsumHelper

Namespaces
namespace	PROJECT_NS
	< http://warp.povusers.org/FunctionParser/fparser.html

Functions
template<typename T >
void	PROJECT_NS::einsum (EinsumHelper &EH, const std::vector< T * > &data_inputs, T *data_output)
template<typename T >
void	PROJECT_NS::einsum (const std::string &einsum_expression, std::vector< T * > data_inputs, const std::vector< std::vector< std::size_t > > &shape_inputs, T *data_output, const std::vector< std::size_t > &shape_output={})

Detailed Description

this file provides einsum operation

About the rules in einsum operations provided by "einsum.h"

In this documentation, we define key terms related to the einsum operation:

• einsum label: Refers to the labels assigned to the indices of the operands involved in the einsum operation. For example, 'a', 'b', 'c' could be operand labels.
• einsum shape: Describes the shape or dimensions of a tensor corresponding to each operand. For instance, "abc" could represent the shape of a tensor.
• einsum expression: Specifies the einsum operation to be performed, indicating the contraction pattern of indices between operands. For example, "ab,bc->ac" defines how the indices from two operands are contracted to produce the final output.

einsum label:

• fixed label: expressed as [name]. It cannot appear in user's deduction!
• inner label: appeared in user's deduction or only appears once in summation.
• outer label: not in user's deduction or appears multiple times in summation.

rules for einsum expression:

• user's deduction: -> indicates for einsum result. Then all (non-fixed) labels appear behind -> are treated as outer labels, while those not appear behind -> are used as inner labels.
• automatic deduction: if -> is not provided in einsum expression. The inner/ outer labels are seperated by the times they appear in summation.

Declaration

This file provides a einsum operation with an easy realization, the performance is not optimized so well. Based on some test, there are about 20x slower than in optimized loop in pure C.

benckmark cases

the following benchmark test is passed:

std::size_t L = 2 * 2 * 2 * 2 * 3 * 3 * 3 * 3;
std::vector<int> A(L, 0);
for (int z = 0; z < L; ++z) {
    A[z] = z % 3 - (z % 5) * (z % 5) + (z % 7);
}
std::vector<int> res(L, 0);
einsum("i", {A.data()}, {{L}}, res.data(), {L});
ARRAY_SHOW(res.data(), 1, 1);
einsum("i->", {A.data()}, {{L}}, res.data(), {1});
ARRAY_SHOW(res.data(), 1, 1);
einsum("ikkkji->j", {A.data()}, {{2, 3, 3, 3, 12, 2}}, res.data(), {12});
ARRAY_SHOW(res.data(), 1, 12);
einsum("ikkkji->ik", {A.data()}, {{2, 3, 3, 3, 12, 2}}, res.data(), {2, 3});
ARRAY_SHOW(res.data(), 2, 3);
einsum("i,i", {A.data(), A.data()}, {{L}, {L}}, res.data(), {1});
ARRAY_SHOW(res.data(), 1, 1);
einsum("ik,ik", {A.data(), A.data()}, {{16, 81}, {16, 81}}, res.data(), {1});
ARRAY_SHOW(res.data(), 1, 1);
einsum("ik,ki", {A.data(), A.data()}, {{16, 81}, {81, 16}}, res.data(), {1});
ARRAY_SHOW(res.data(), 1, 1);
einsum("ik,kj->ij", {A.data(), A.data()}, {{4, 324}, {324, 4}},
                    res.data(), {4, 4});
ARRAY_SHOW(res.data(), 4, 4);
einsum("ik,kj,ljjlll->il", {A.data(), A.data(), A.data()},
       {{4, 324}, {324, 4}, {3, 4, 4, 3, 3, 3}},
       res.data(), {4, 3});
ARRAY_SHOW(res.data(), 4, 3);

which is coincided with the results by numpy's einsum() function:

import numpy as np
L = 2*2*2*2*3*3*3*3
z = np.arange(L)
A = (z%3) - (z%5)**2 + (z%7)
print(np.einsum('i', A))
print(np.einsum('i->', A))
print(np.einsum('ikkkji->j', A.reshape((2,3,3,3,12,2))))
print(np.einsum('ikkkji->ik', A.reshape((2,3,3,3,12,2))))
print(np.einsum('i,i', A, A))
print(np.einsum('ik,ik', A.reshape((16,81)), A.reshape((16,81))))
print(np.einsum('ik,ki', A.reshape((16,81)), A.reshape((81,16))))
print(np.einsum('ik,kj->ij', A.reshape((4,324)), A.reshape((324,4))))
print(np.einsum('ik,kj,ljjlll->il', A.reshape((4,324)),
                 A.reshape((324,4)), A.reshape((3,4,4,3,3,3))))

the results are:

[ 0  1  0 ... -4 -9  2]
-2589
[-25  -9  -9  -8 -11 -22  -8 -15  -5 -10 -21  -5]
[[-18 -28 -33]
 [-27 -21 -21]]
56293
56293
52891
[[-2724  3071  8230  7447]
 [-8259 -3074  3047  8535]
 [ 6290 -8694 -3109  3442]
 [ 8340  6031 -8557 -2810]]
[[ 83744  54125  79687]
 [ 57250 -22579  -1748]
 [ -9172 -21858 -39479]
 [-39026  55563 -10344]]

Author

Xin He

Date

2024-03

Version

1.0

Copyright

GNU Lesser General Public License (LGPL)

         Copyright (c) 2024 Xin He, Liu-Group

This software is a product of Xin's PhD research conducted by Professor Liu's Group at the College of Chemistry and Molecular Engineering, Peking University. All rights are reserved by Peking University. You should have received a copy of the GNU Lesser General Public License along with this software. If not, see https://www.gnu.org/licenses/lgpl-3.0.en.html

[logs]:

Date	Description
2024-03-29	initial version. The shape_inputs and shape_output are consistent with that interface Basic_Shape in the file Shape.h.

Definition in file Einsum.h.
